SLVLP
DESCRIPTION
The SLVLP series of low-voltage power supplies includes models with positive and negative polarity, with an output voltage from 12 V to 1000 V and power from 300 W to 5000 W. SLVLP sources support CV / CC / CP operating modes and provide accurate setting and stable maintenance of output voltage and current over a wide range of parameters. This allows them to be used for powering and testing electronic devices, power modules, power supplies, battery systems and telecommunications equipment.
FEATURES
- Input power protection
- Overload and short circuit protection
- Output over/under voltage protection
- Stabilization modes: CV / CC / CP
- Active PFC with 99% efficiency
- Support for digital interfaces RS-232, RS-485, USB, Ethernet
- Intuitive user software
- Operating modes can be programmed
- Production, support and service - Russian Federation
APPLICATION
- Laboratory and measurement benches
- Automated test equipment (ATE)
- Production and inspection benches
- Testing of power and low-voltage electronics
- Powering telecommunications and server equipment
- Research and development work
- Integration into automated control and monitoring systems
| The lineup | Rated power, W | Maximum output voltage at rated power, V | Peak-to-peak output voltage ripple, % | ||||||
|---|---|---|---|---|---|---|---|---|---|
| SLVLP-300-XX* | 300 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | 1000 | |||
| SLVLP-600-XX* | 600 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | 1000 | |||
| SLVLP-1000-XX* | 1000 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | 1000 | |||
| SLVLP-1800-XX* | 1800 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | 1000 | |||
| SLVLP-3600-XX* | 3600 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | 1000 | |||
| SLVLP-5000-XX* | 5000 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 0.1 |
| 150 | 200 | 300 | 400 | 600 | 800 | - | |||
* Polarity: P – positive, N – negative.
