SLVHP
DESCRIPTION
The SLVHP series of low-voltage power supplies includes models with positive and negative polarity, with an output voltage from 250 V to 2000 V and power from 5 kW to 60 kW. SLVHP sources support CV / CC / CP operating modes and provide accurate setting and stable maintenance of output voltage and current over a wide range of parameters. This allows them to be used for capacitor charging, powering and testing electronic devices, power modules, power supplies, battery systems and telecommunications equipment.
FEATURES
- Input power protection
- Overload and short circuit protection
- Output over/under voltage protection
- Stabilization modes: CV / CC / CP
- Active PFC with 99% efficiency
- Support for digital interfaces RS-232, RS-485, USB, Ethernet
- Intuitive user software
- Operating modes can be programmed
- Production, support and service - Russian Federation
APPLICATION
- Capacitor charging
- Laboratory and measurement benches
- Automated test equipment (ATE)
- Production and inspection benches
- Testing of power and low-voltage electronics
- Powering telecommunications and server equipment
- Integration into automated control and monitoring systems
| The lineup | Rated power, W | Maximum output voltage at rated power, V | Peak-to-peak output voltage ripple, % | ||||
|---|---|---|---|---|---|---|---|
| SLVHP-5-XX* | 5000 | 250 | 500 | 1000 | 1500 | 2000 | 1 |
| SLVHP-10-XX* | 10000 | 1 | |||||
| SLVHP-20-XX* | 20000 | 1 | |||||
| SLVHP-30-XX* | 30000 | 1 | |||||
| SLVHP-40-XX* | 40000 | 1 | |||||
| SLVHP-50-XX* | 50000 | 1 | |||||
| SLVHP-60-XX* | 60000 | - | - | 1 | |||
* Polarity: P – positive, N – negative.
